Conlan C1000LP - Introduction to Conlan Keypad C1000 LP; Installation and Wiring Guide

3
1. Introduction
C1000LPisalowpowerkeypadthatworksonelectroninclockswithopencollector
and/or H-Bridge mode.
InstandbymodeistheyellowLEDislit(● ○ ○)
BycorrectcodelightsyellowandgreenLED(● ● ○)
By incorrect code lights the red LED (○ ○ ●)
C1000LPhasabuzzerforindicatingwhilekeying,correctcode,incorrectetc.and2
transistoroutputs,independantfromeachother,sotheC1000LPcangiveaccessby
code.
TheC1000LPisastandaloneunit,thecanbeprogrammeddirectlybyMastercode
and Service code.
2. Installation
Mount the reader on a even surface.
Connectthewirestopowersupply,doorstrikeetc.(usesupplieddiode)
Wire colours
Note: Right after applying the voltage all LED’s lights and the buzzer sounds do not
touchthereaderuntilltheyellowLEDlightsandthebuzzerissilent.
2 - 16 VDC
0V GND
Output 2 open collector, 500 mA, 0V active
Output 1 open collector, 500 mA, 0V active
REX (IN2)
Feedback (IN1)
External controlling red LED, 0V active
External controlling green LED, 0V active
1 3
5
7 9
2
4 6
8
0
