Consew P1206RB - Page 21

1.CastingMechanism
Line PartNumber Description Qt. Notes
1 100‐1001 Faceplate 1
2 100‐1002 Screw 2
3 100‐1003 Threadguide 1
4 100‐1004 Threadguide 1
5 100‐1005 Screw 3
6 100‐1006 Threadguideassy. 1
6‐1 100‐1007 Threadguide 1
6‐2 100‐1008 Pre‐tensionstud 1
6‐3 100‐1009 Tensiondisc 2
6‐4 100‐1010 Tensionspring 1
6‐5 100‐1011 Adjustingscrew 1
7 100‐1012 Setscrew 1
8 100‐1013 Threadguide 1
9 100‐1014 Threadtensionbracketassy. 1
9‐1 100‐1015 Tensionstud 1
9‐2 100‐1016 Tensionnut 1
9‐3
100‐
1017 Tensionspring 1
9‐4 100‐1018 Discpresser 1
9‐5 100‐1019 Disc,tension 2
9‐6 100‐1020 Threadtake‐upspring 1
9‐7 100‐1021 Threadtensionbracket 1
9‐8 100‐1022 Setscrew 1
9‐10 100‐1023 Stopper 1
9‐11 100‐1024 Oring 1
10 100‐1025 Setscrew 1
11 100‐1026 Cover 1
12 100‐1027 Screw 1
13 100‐1028 Threadretainer 1
14 100‐1029 Screw 1
15 100‐1030 Tensionreleasepin 1
16 100‐1031 Tensionreleasestud 1
17 100‐1032 Rubberplug 1
18 100‐1033 Rulerplate
1
19
100‐1034 Screw 2 GB936
20 100‐1035 Bedleg 4
21 100‐1036 Washer,spring 4
22 100‐1037 Arm 1
23 100‐1038 Bed 1
24 100‐1039 Slideplateassy. 1
24‐1 100‐1040 Slideplate 1
24‐2 100‐1041 Springplate 1
24‐3 100‐1042 Screw 2
25 100‐1043 Needleplate 1
26 100‐1044 Screw 2
27 100‐1045 Bobbinthreadwinderassy. 1
28 400‐1244 Screw 3
29 100‐1046 Cutter 1
30 100‐1047 Screw 2
31 100‐1048 Bobbinthreadtensionassy. 1
32 100‐1049 Screw 1
33 100‐1050 Motorcover 1
34 100‐1051 Screw 5 GB/818M5X25
35 100‐1052 Backcover 1
36
100‐
1053 Seal 1
37 100‐1054 Screw 4
38 200‐1377 Washer 4
