Consew P1206RB - Hook Mechanism

6.Hookmechanism
Line PartNumber Description Qt. Notes
1 100‐1243 Verticalshaft 1
2 100‐1244 Bevelgear,uppershaft 1
3 400‐1203 Setscrew 8
4 100‐1245 Bevelgear,verticalshaft,U1
5 100‐1246 Bevelgear,lowershaft 1
6 100‐1247 Bevelgear,verticalshaft,L1
7 100‐1248 Bush,verticalshaft,U1
8 100‐1249 Bush,verticalshaft,
L
1
9 100‐1060 Screw 2
10 100‐1250 Bobbincase 1
11 100‐1251 bobbin 1
12 100‐1252 Hookassy. 1
13 100‐1253 Lowershaft 1
14 100‐1254 Filter 1
15 100‐1255 Screw 1
16 100‐1256 Bush,lowershaft,
L
1
17 100‐1257 Adjustingscrew,oil 1
18 100‐1258 Adjustingspring 1
19 100‐1259 Collar 1
20 100‐1184 Screw 2
21 100‐1260 Bush,lowershaft,R1
22 100‐1067 Screw 2
23 100‐1261 Plunger 1
24 100‐1262 Spring 1
25 100‐1263 Holderplate 1
26 100‐1264 Screw 1
27 100‐1265 B/caseholderpositionbracket 1
28 100‐1266 Screw 1
29 100‐1267 Washer 1 GB936
30 100‐1268 Oiltube 1
31 100‐1269 Oilseal 1
