Consew P1206RB - Needle Bar and Thread Take-Up Mechanism

2.Needlebarandthreadtake‐upmechanism
Line PartNumber Description Qt. Notes
1 100‐1055 Uppershaft 1
2 100‐1056 Robbercap 1
3 100‐1057 Collar 1
4 400‐1105 Screw 2
5 100‐1058 Bush,L1
6 100‐1059 Bush,M1
7 100‐1060 Setscrew 1
8 100‐1061 Bearing,R1ɸ20xɸ42x12
9 100‐1062 Oilseal 1
10 100‐1063 Handwheel 1
11 100‐1064 Screw 2
12 100‐1065 Threadtake‐upleverset 1
13 100‐1066 Supportshaft 1
14 100‐1067 Setscrew 2
15 100‐1068 Threadtake‐upcrank 1
16 100‐1069 Screw 1
17 400‐1203 Screw 1
18 100‐1070 Screw 1
19 100‐1071 Screw 1
20 100
‐1072
Bush,needlebar,upper 1
21 100‐1073 Robbercap 1
22 100‐1074 Bush,needlebar,lower 1
23 100‐1075 Frictionwheel 1
24 100‐1076 Needlebar 1
25 100‐1077 Threadguide 1
26 100‐1078 Needle 1 135X17#23
27 200‐1166 Setscrew 1
28 100‐1079 Needlebarclampassy. 1
28‐1 100‐1080 Needlebarclamp 1
28‐2 100‐1081 Setscrew 1
29 100‐1082 Washer 1
30 100‐1083 Felt 1
31 100‐1084 Shaftcoupling 1
32 100‐1085 Screw 4 GB/T65M5X20
33 100‐1086 Screw 4 GB/T8595
34 100‐1087 Springwasher 4 GB/T95
5
35
100‐1088 Washer 4
36 100‐1089 Screw 2
19
