Consew P1206RB - Feed Mechanism

4.Feedmechanism
Line PartNumber Description Qt. Notes
1 100‐1116 Feeddog 1
2 100‐1117 Feedbar 1
3 100‐1118 Washer 1
4 100‐1119 Shaft 1
5 100‐1120 Screw 2
6 100‐1121 Feedrockarm 1
7 100‐1122 Screw 2
8 100‐1123 Screw 1
9 100‐1124 Feedshaft 1
10 100‐1125 Retainingring 2 GB894.115
11 100‐1126 Bush,L2
12 100‐1057 Collar 2
13 400‐1105 Setscrew 4
14 100‐1127 Feedrockerarm 1
15 100‐1128 Stud 1
16 100‐1129 Setscrew 1
17 400‐1027 Screw 1
18 100‐1130 Feedliftingarm 1
19 100‐1131 Pin 1
20 100‐1132 Bush,M2
21 100‐1133 Washer 2
22 100‐1134 Feedlifting
arm
1
23 100‐1135 Shaft 1
24 100‐1120 Screw 2
25 400‐1027 Screw 1
26 100‐1136 Connectingstud 1
27 100‐1137 Feedregulator 1
28 100‐1138 Screw,L1
29 100‐1139 Screw,S1
30 100‐1140 Bush 1
31 100‐1141 Shaft 1
32 100‐1142 Rubbercap 1
33 100‐1143 Pinassy.Lever 1
34 100‐1144 Spring,extension 1
35 100‐1145 Screw 1
36 100‐1146 Reversestitchingleverassy. 1
36‐1 100‐1147 Reversestitchingleve
r
1
36‐2 100‐1148 Springhookpin 1
37 100‐1149 Shaft 1
38 100‐1150 Oring 1 6.3X1.8GGB3452.1‐92
39 100‐1151 Adjustingscrew 1
40 100‐1152 Oring 1 14X2.4
41 100‐1153 Stitchlengthdial 1
42 100‐1154 Stitchlengthplate 1
43 100‐1155 Supportbush 1
23
