Consew P1206RB - Presser Foot Mechanism

3.Presserfootmechanism
Line PartNumber Description Qt. Notes
1 100‐1090 Presserbarlifter 1
2 100‐1091 Screw 1
3 100‐1092 Liftercrank 1
4 100‐1093 Oring 1 GB3452.14.5X1.8G
5 100‐1094 Lifterlever 1
6 100‐1095 Guideplate 1
7 100‐1096 Screw 1
8 100‐1097 Screw 2
9 100‐1098 Collectingrod 1
10 100‐1099 Screw 1
11 100‐1100 Lever 1
12 100‐1101 Spring,extension 1
13 100‐1102 Kneelifterbar 1
14 100‐1103 Springhook 1
15 100‐1104 Shoulderscrew 1
16 100‐1105 Bush 1
17 100‐1106 Presserbar 1
18 100‐1107 Guidebracket 1
19 100‐1060 Screw 2
20 100‐1108 Spring,compression 1
21 100‐1109 Adjustingscrew,
presser 1
22
100‐1110 Adjustingnut,presser 1
23 100‐1111 Presserfoot,inside 1
24 100‐1112 Screw 1
25 100‐1113 Threadguide 1
26 100‐1114 Fingerguard 1
27 100‐1115 Washer 1
21
