7
Figure 5.
(Actual probe may be different with the probe as figure 4,please accept the actual probe with the
device )
Attention:
CLICK = short press of power button and PRESS = prolonged push of power button (1sec)
B. Change display direction
On the measuring interface, enter the clock interface by Click the button, and then Click the button
to change the display direction within 30 seconds.
C. Enter and exit the clock interface
a) On the measuring interface, Click the button in order to enter the clock interface, and it will
automatically return to the measuring interface if there are no more operations within 30 seconds.
b) On the measuring interface, Press the button for about 10 seconds in order to enter the clock
interface, and the device would return to the measuring interface by Press the button for about 10
seconds again.
D. Pause alarm
a) Alarm including the alarm of measure data's going beyond the limits, the alarm of low-voltage,
the alarm of probe or finger's out of position.
b) On the measuring interface, if the alarm function is on, during the period of alarming, you can
pause it by Click the button, but the function will be renewed in about 60 seconds.
c) If you want to turn off the alarm for good, you should enter the menu for operation.
E. Menu operations
When the device is under the measuring interface, Press the button for about 1 second in order to
enter the menu interface shown as figure 5. Users can adjust the setting through the main menu, such
as backlight, alarm, clock, data transmission (with the data line), data storage, and power off. The
specific operation methods are as the following:
