16 MAINTENANCE OF MACHINES
 DAILY MAINTENANCE
- Clean the hot water outlet and the steam outlets with a scouring pad:
o Use a needle to keep the diffuser outlets unclogged.
o Then purge by opening the tap a few seconds.
- Clean the drip tray and the basin, removing them from the machine.
- Remove the filter-holder from the groups and clean the seal injection filter-holder with the brush.
- Use the automatic process cleaning:
o Insert blind filter in the filter holder and place the CONTI cleaning tablet code n°466662
o Engage this filter-holder on the group to be cleaned
o Simultaneously press the 5th (continuous) and the first key (1 espresso)
o The automatic cleaning process of the group is started in 3 steps:
o The process is shown on the display.
o Follow the instructions on the display.
o Repeat this procedure on each group.
- Brush the filters in water containing detergent:
o In order to unclog the holes
o Never use a needle or a flame.
 HALF YEAR MAINTENANCE:
- A kit n° 480330, for the following operation is available for sale.
- For each group:
o Remove the sprinkler, diffuser, and seal gasket.
o Scrub the gasket groove and the supplying hole on the group head.
o Clean the two parts of the diffuser. Clear all the holes with a needle.
o Reassemble the 2 parts of the diffuser on the group head
o Place NEW Filter gasket, and NEW sprinkler.
- Remove and clean the level sensor (limestone deposit).
