17 ELECTRONIC DIAGRAM STANDARD VERSION
17.1 DESIGNATION OF USEFUL CODES
REF. DESIGNATIONS
ON/ OFF ON / OFF BUTTON
CE ELECTRONIC CARD (MOTHER BOARD)
CV X FLOWMETER
SONDE 1 TEMPERATURE PROBE FOR STEAM BOILER
SONDE 2 TEMPERATURE PROBE FOR STEAM CONTROL SYST
CN1 / CN2 / CN3 CONNEXION FOR CONTROL COFFEE BUTTONS GR X
EV EE
FILLING UP SOLENOID VALVE
EV GR X COFFEE GROUP X SOLENOID VALVE
EV LV STEAM CONTROL SYSTEM SOLENOID VALVE
MP COMPLETE PUMP
EV THE TEA SOLENOID VALVE (HOT WATER)
RC HEATING ELEMENTS
RS X STATES RELAYS 1/ 2 /3
SN LEVEL SENSOR
KLIXON KLIXON
BP BUTTON ON/OFF
EV AIR AIR SOLENOID VALVE
EV LAV LAV SOLENOID VALVE
1 marron brown
2 rouge red
3 orange orange
4 jaune yellow
5 vert green
6 bleu blue
7 violet violet
8 gris grey
9 blanc white
0 noir black
CODE COULEURS FILS
CABLE COLOUR CODE
