19. TECHNICAL DOCUMENTS
WATER SUPPLY DRAIN POWER
*Minimum pressure 24 Psi
*3/8" male connector
*Water supply pipes resistant to
145 Psi
*TH=<7°
*Without pressure
*1/2" male connector
*Ensure that water can not
return to the machine
400V - 50Hz
three-phase
(factory standard)
or
230V - 50/60Hz
single-phase
By commutation
on the machine
Except UL and ULC
230V - 60Hz
MACHINE TYPE HEATING POWER INSTALLED POWER POWER USED
W W Amp.
230V 400V
2G STANDARD 2800*/4000** 3200*/4400** 15*/20** 9*/12**
3G STANDARD 3400*/4000** 3800*/4400** 18*/20** 10*/12**
4G STANDARD 4000 4400 20 12
2G/3G/4G UL 4000 4400 20 12
* before 2002/10
** since the 2002/10
CAPACITY OF BOILER IN LITERS
2G 3G 4G
TOTAL 14 21 24,9
VOLUME OF HOT WATER 10,5 15,7 18,5
VOLUME OF STEAM 3,5 5,3 6,4
WEIGHT
(Kg)
WEIGHT WHEN
WORKING (Kg)
2G 60 70
3G 75 91
4G 88 106
