User's Manual CS1171 Hand-Held Programmer
Page 11 of 56 Control Solutions LLC
CS1171 Hand-Held Programmer
This section of the document describes the HHP layout, navigation and interface.
Unit Layout
The programmer contains a Liquid Crystal Display (LCD) and five button keypad on the
front of the unit, and one RJ45 port on the back. See Figure 3 and Figure 4.
Display
Information is output to the user through the 16 character x 2 line LCD display
located on the front of the unit.
