Wiring Configurations
When using a non-display (refer to Figure 5 - Figure 9), the HHP must be directly
connected to the controller. If the programming connector style is an 8-pin (RJ45 Telco type
connector) and the display is connected to the same 8-pin connector, the display must be
disconnected to use the HHP.
Table 5 lists the wiring configurations for Control Solutions motor controllers.
Controller
Type
Configuration
Programming
Connector
Programming
Connector PCB
Label
Motor
Controller
Type
CS1103
See Figure 5
8-pin Telco
JP2
Single
CS1106
See Figure 6
4-pin
JP1
Single
CS1107
See Figure 7
4-pin
J16
Single
CS1108
See Figure 5
8-pin Telco
JP1
Single
CS1109
See Figure 5
8-pin Telco
JP1
Single
CS1112
See Figure 6
4-pin
JP1
Single
CS1115
See Figure 8
4-pin
J2
Single
CS1117
See Figure 9
4-pin
J16
Quad
CS1125
See Figure 5
8-pin Telco
JP2
Single
CS1126
See Figure 5
8-pin Telco
JP2
Dual
Table 5 - CSLLC Motor Controllers
An intelligent display e.g. CS1151A or CS1161 must be used in
conjunction with the HHP when using the CS1303 Y-Adapter or the
HHP will not function. The CS1155 is not an intelligent display.
