CONTROL SOLUTIONS CS1171 - Parameter Information

User's Manual CS1171 Hand-Held Programmer
Page 45 of 56 Control Solutions LLC
Parameter Information
Table 8 - Table 14 provide a listing of the HHP parameters and their read/write (R/W)
capability, range, unit of measure and whether the parameter is dynamic. The last column
of each table indicates whether the parameter can be modified by the OEM HHP, Dealer
HHP, or both. The column key for HHP is:
O = OEM only
B = OEM and Dealer
Main Menu
Parameter
R/W
Range
Measure
Dynamic
HHP
FAULT CODE!
Read only
00-FF
Hex
Y
B
FWD speed
Y
0-100
%
N
B
RVS speed
Y
0-100
%
N
B
Min speed
Y
0-100
%
N
O
FWD accel
Y
0-100
%
N
B
FWD decel
Y
0-100
%
N
B
FWD>RVSdcl
Y
0-100
%
N
B
RVS accel
Y
0-100
%
N
B
RVS decel
Y
0-100
%
N
B
RVS>FWDdcl
Y
0-100
%
N
B
Motor comp
Y
0-240
Decimal
N
B
Indoor mode >
–
–
–
–
B
Throtl scl
Y
0-255
Decimal
N
O
Deadband
Y
0-255
Decimal
N
O
Failband
Y
0-255
Decimal
N
O
Push speed
Y
0-100
%
N
O
Hold time
Y
0-100
%
N
O
Ramp shape
Y
0-15
Decimal
N
O
Comp rspns
Y
0-100
%
N
O
Brake time
Y
0.00-2.55
–
N
B
Keyoff dcl
Y
0-100
%
N
O
Batt res
Y
0-255
†
Coefficient
N
O
Timeout
Y
0-240
Minutes
N
B
Flash V
Y
18-23
Volts
N
B
Full V
Y
23.1-26
Volts
N
B
†
Note: Refer to the parameter description on page 26
