Debug Sub-menu
Parameter
R/W
Range
Measure
Dynamic
HHP
Short ckt
Read only
On/off
–
Y
O
Off push
Read only
On/off
–
Y
O
Max speed
Y
0-100
%
Y
B
Analog in
Read only
0-100
%
Y
B
Throt flags
Read only

00-FF
Hex
Y
B
Battery V
Read only
0-99
Volts
Y
B
Temp
Read only
-20 to +147
C
Y
B
Current A
Read only
-999.9 to +999.9
Amps
Y
B
Buttons
Read only
00-FF
Hex
Y
B
Indoor pin
Read only
On/off
–
Y
B
Indoor mode
Read only
On/off
–
Y
B
QStop pin
Read only
On/off
–
Y
O
Quick stop
Read only
On/off
–
Y
B
Brk rel pin
Read only
On/off
–
Y
O
Brake rel
Read only
On/off
–
Y
B
Charging
Read only
On/off
–
Y
B
Keyswitch
Read only
On/off
–
Y
O
Reverse pin
Read only
On/off
–
Y
O
Reverse
Read only
On/off
–
Y
B
Chrge time
Read only
0000-FFFF
Hex
Y
B
Charge mode
Read only
00-08
Hex
Y
B

Note: Bit mapped
Table 14 - HHP Debug Sub-menu Parameter Reference
