User's Manual CS1171 Hand-Held Programmer
Page 35 of 56 Control Solutions LLC
Options Sub-Menu
When set to On, enables a horn beep (if equipped) when the
controller is in reverse.
When set to On, enables a horn beep (if equipped) when the
controller is in reverse – for unidirectional throttle only.
When set to On, Beep enables a horn beep (if equipped) when a
controller error code is present. The horn will pulse out the error
code, similar to the LED modulation for an error code.
When set to On, asserting the quick stop input triggers a
programmable softer stop. When set to Off, asserting quick stop
triggers an abrupt stop.
When set to On, a sample battery voltage is displayed. This is
used for battery related testing and problem diagnosis. Turn off
when finished with diagnostics.
When set to On, the controller jumps to drive mode when charging
completes. If enabled, the key must be on to jump to drive mode.
When set to Off, the controller turns off when charging completes.
When set to On, the controller performs general power-up self-
diagnostics. Diagnostics are not performed when powering up in
charge mode.
When set to On, electromagnetic (EM) brake diagnostics are
enabled at power-up and also during operation. When set to Off,
diagnostics are not performed on the EM brake output. Most
applications with an EM brake require this option to be enabled as
part of compliance standards.
When set to On, the current limit characteristic of the controller will
recover quickly in response to motor current, versus a slower
cutback and recover.
When set to On, the current limit decay function changes to an
abrupt step function, such that after a time defined by Cur time;
the current limit will drop from Cur lim hi to Cur lim lo. When set
to Off, current limit will follow a normal linear decay function. See
Figure 16.
When set to On, the status LED will flash when charging starts.
To Next Page
