Parameter
Description
In/Out cur
When turned On, uses the upper bound current limit setting when
in Outdoor mode, and the lower bound current limit setting when in
Indoor mode.
Shabat
When turned On, and properly configured, the motor controller
enters indoor mode and uses defined creep speed parameters.
Full e2 sel
When turned On, allows a section of memory to be accessed that
stores creep speed information used by Shabat.
Misc 1&2
To configure these pins contact CSLLC, refer to page 53.
Misc 3&4
To configure these pins contact CSLLC, refer to page 53.
Misc1 invert
Inverts the operation state of the Misc 1 input.
Misc2 invert
Inverts the operation state of the Misc 2 input.
Misc3 invert
Inverts the operation state of the Misc 3 input.
Misc4 invert
Inverts the operation state of the Misc 4 input.
Shutdown V
Voltage level of the battery, that when reached, shuts down the
controller.
EMBrake V
Sets the desired EM brake voltage. The EM brake output is pulse
width modulated to achieve values lower than the actual battery
voltage. Output is independent of the battery voltage, but can
never be higher than the absolute battery voltage.
