CONTROL SOLUTIONS CS1171 - Debug Sub-Menu

CS1171 Hand-Held Programmer User's Manual
Control Solutions LLC Page 40 of 56
Debug Sub-Menu
Parameter
Description
Fault Code
Displays the controller's current fault code, if present. Will display 00
if no fault present.
Fault Log
Displays the controller’s most recent fault log. To access the log:
Step
Action
1
On the HHP from the Main menu, scroll down to the
Debug > menu parameter
2
Press > to enter the Debug menu
3
Scroll down to the Fault Log parameter
4
Press > to select the parameter
5
Press + to access the next fault, or – to access the
previous fault
Up to 16 faults can be stored. FF or 00 represent a blank fault log
location. (See www.controls.com/index.php/support/troubleshoot/hhp for
error code explanations on all controllers)
Product ID
Displays the controller’s 4-digit CS product identification (e.g.
CS1108 would display 1108).
FW rev h
Displays the firmware revision of the controller.
FW rev l
Displays the firmware revision of the controller.
Serial # >
Displays the controller’s serial number. To access the serial number:
Step
Action
1
On the HHP from the Main menu, scroll down to the
Debug > menu parameter
2
Press > to enter the Debug menu
3
Scroll down to the Serial # > parameter
4
Press > to select the parameter
5
Press < to return to the Debug menu
PWM
Displays in real time, the set PWM duty cycle percent of the drive
system output (M1+/M1- motor terminals).
When a fault code is displayed, the > can be pushed
to momentarily display the text associated with the
error code.
