CONTROL SOLUTIONS CS1171 - Page 41

User's Manual CS1171 Hand-Held Programmer
Page 41 of 56 Control Solutions LLC
Parameter
Description
Speed
Displays in real time the speed percentage that the controller
attempts to maintain.
Throt V
Displays in real time the throttle input voltage in volts. There is a two
place decimal point that is not displayed on the programmer, so a
displayed value of 0100 would equal 1.00V, and a displayed value of
0250 would equal 2.50V.
Throt val
Displays in real time the absolute throttle percentage from neutral
with respect to the throttle input range.
Throt center
Displays in real time when the throttle is in the center position.
Throt fault
Displays in real time when there is a throttle fault.
Short ckt
Displays in real time if there is a short circuit in the motor circuit.
Off push
Displays in real time, On if the vehicle is being pushed while the key
is off and charging mode is off.
Max speed
Displays in real time the set maximum speed percentage, which can
be set by an intelligent display (CS1151A, CS1161). Check Throt
flags to see which input is used to set Maximum Speed.
Analog in
Displays in real time the Analog input voltage relative to the
controller’s +5V power supply, in terms of percentage.
Throt flags
Displays different throttle and max speed option configurations.
Enabled = 1, Disabled = 0. They are defined as follows:
No.
Option(s)
Hex
Code
Description
1
Inverted Throttle
01
Changes the driving throttle
actuation so that a normal
forward actuation of the throttle
results in reverse operation from
the controller
2
Max Speed =
Analog Input
04
Enables analog input to be used
for max speed control
3
Max Speed = Max
Speed
10
Enables max speed input to be
used for max speed control
4
Max Speed = Serial
throt
40
Enables Serial throt input to be
used for max speed control
5
1 & 2
05
(See 1 & 2 above)
6
1 & 3
11
(See 1 & 3 above)
7
1 & 4
41
(See 1 & 4 above)
