CONTROL SOLUTIONS CS1171 - Page 42

CS1171 Hand-Held Programmer User's Manual
Control Solutions LLC Page 42 of 56
Parameter
Description
Battery V
If Debug volts is enabled, Battery V displays in real time the
battery voltage. Otherwise, it displays the battery capacity. There is
a two place decimal point that is not displayed on the programmer,
so a displayed value of 0100 would equal 1.00V, and a displayed
value of 0250 would equal 2.50V.
Temp
Displays in real time the temperature of the drive FET transistors.
Current A
Displays in real time the motor current in Amps.
Buttons
Each one of the eight bits that make up the hexadecimal value
represents one button on a deluxe display. A button pressed = 0, not
pressed = 1. They are defined as follows:
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Break
Release
Seat
Up
Head
light
Seat
Down
Right
Turn
Signal
Speed
Up
Left
Turn
Signal
Speed
Down
If only one button is pressed at a time, the hexadecimal codes
displayed will be as follows:
Break
Release
Seat
Up
Head
light
Seat
Down
Right
Turn
Signal
Speed
Up
Left
Turn
Signal
Speed
Down
7F
BF
DF
EF
7F
FB
FD
FE
If more than one button is pressed at a time, a combination of bits
will be 0 at the same time. There are 255 possible combinations.
This feature can be helpful to determine which button(s) may be
stuck down on a deluxe display e.g. FF = no buttons pressed, FE =
Speed Down, FC = Speed Down and Left Turn Signal, 00 = All
Buttons presses.
Indoor pin
Displays in real time whether the Indoor mode (drive mode 2) is on
or off.
Indoor mode
Displays in real time, On when in Indoor mode (drive mode 2).
QStop pin
Displays in real time, if the controller is seeing a quick stop input.
Quick stop
Shows On when Quick Stop is active.
Brk rel pin
Displays in real time, On when the controller sees a high external
brake release input.
Brake rel
Displays in real time, On when Brake Release is active.
Charging
Displays in real time, On when Charge Mode is active.
