Functions Sub-menu
Parameter
R/W
Range
Measure
Dynamic
HHP
Clr flt log
Y
Y/N
–
N
B
Recall Init
Y
Y/N
–
N
B
Recall Fact
Y
Y/N
–
N
B
Save to Mem1
Y
Y/N
–
N
B
Recall Mem1
Y
Y/N
–
N
B
Save to Mem2
Y
Y/N
–
N
B
Recall Mem2
Y
Y/N
–
N
B
Save to Mem3
Y
Y/N
–
N
B
Recall Mem3
Y
Y/N
–
N
B
Save to Mem4
Y
Y/N
–
N
B
Recall Mem4
Y
Y/N
–
N
B
Save to Mem5
Y
Y/N
–
N
B
Recall Mem5
Y
Y/N
–
N
B
Save to Mem6
Y
Y/N
–
N
B
Recall Mem6
Y
Y/N
–
N
B
Save to Mem7
Y
Y/N
–
N
B
Recall Mem7
Y
Y/N
–
N
B
Table 13 - HHP Functions Sub-menu Parameter Reference
Debug Sub-menu
Parameter
R/W
Range
Measure
Dynamic
HHP
Fault Code
Read only
00-FF
Hex
N
B
Fault Log
Read only
00-FF
Hex
N
B
Product ID
Read only
–
–
N
B
FW rev h
Read only
00-FF
Hex
N
B
FW rev l
Read only
00-FF
Hex
N
B
Serial # >
Read only
–
–
N
B
PWM
Read only
0-100
%
Y
*B
Speed
Read only
0-100
%
Y
O
Throt V
Read only
0-5
Volts
Y
B
Throt val
Read only
0-100
%
Y
B
Throt center
Read only
On/off
–
Y
B
Throt fault
Read only
On/off
–
Y
B
*Note: Different order to menu items
