Commander S100 Step by Step Guide 4
English
Table 1-2 Motor cable and fuse/MCB selection
* For UL installations, the circuit breaker must be listed under category control number DIVQ / DIVQ7, rated 600 Vac
with a short circuit rating > 10 kA. In other countries, circuit breakers compliant with EN IEC 60947-2 are
recommended, with > 10 kA short circuit breaking capacity.
IEC cable sizes assume Copper conductor, PVC insulation, installation method B2 and ambient temperature of 40 °C
(104 °F). For UL, cables must be rated for 75 °C (167 °F) operation and copper only. To fit a ferrule, 90 °C (194 °F)
rated cable with a reduced cross section is required for some drives.
The voltage rating of fuses and MCBs must be greater than or equal to the highest supply voltage of the
system.
Model
Number
Input
Phases
Max Input
Current
Fuses MCB rating* Cables
IEC
Class
gG
UL
Class
CC, J or
T
IEC UL
IEC60364-5-52
mm
2
UL61800-5-1
AWG
A A A A A Input Output Input Output
110 V
S100-01113 1 7.19 10 10 10 15 1.5 1.5 24 24
S100-01123 1 8.49 10 15 10
15 1.5
1.5 24 24
S100-01133 1 10.4 12 15 12 15
1.5
1.5 22 22
S100-03113 1 14.8 16 20 16 25 2.5 1.5 20 20
S100-03123 1 20.01 25 30 25 25 2.5 1.5 18 18
S100-03133 1 28.54 32 40 32 40 6 1.5 16 16
230 V
S100-01S13 1 3.3 6 6 6 15 1.5 1.5 24 24
S100-01213 3 1.95 4
66151.51.5
24 24
S100-02S11 1 3.3 6
66151.51.5
24 24
S100-01S23 1 3.84 6 6 6 15 1.5 1.5 24 24
S100-01223 3 2.28 4
66151.51.5
24 24
S100-02S21 1 3.84 6
66151.51.5
24 24
S100-01S33 1 4.74 6
66151.51.5
22 22
S100-01233 3 2.84 4
66151.51.5
22 22
S100-02S31 1 4.74 6
66151.51.5
22 22
S100-01S43 1 8.01 10 10 10
15 1.5 1.5
20 20
S100-01243 3 4.74 6 6 6
15 1.5 1.5
20 20
S100-02S41 1 8.01 10 10 10
15 1.5 1.5
20 20
S100-01S53 1 9.51 12 15 12
15 1.5 1.5
18 18
S100-01253 3 5.69 8 10 8
15 1.5 1.5
18 18
S100-02S51 1 9.51 12 15 12
15 1.5 1.5
18 18
S100-01D63 1 / 3 15.28 / 12.60 16 / 16 20 / 15 20 / 16 20 / 15 2.5
1.5
16 16
S100-02S61 1 15.28 16 20 20 20 2.5 1.5 16 16
S100-01D73 1 / 3 18.41 / 14.25 20 / 16 25 / 20 25 / 16 20 / 20
2.5 1.5
16 14
S100-02S71 1 18.41 20 25 25 20 2.5 1.5 16 14
S100-03D13 1 / 3 26.10 / 19.74 32 / 25 35 / 25 32 / 25 30 / 25 4
1.5
14 14
400 V
S100-02413 3 1.92 4 6 6 15 1.5 1.5 24 24
S100-02423 3 2.5
466151.51.5
22 22
S100-02433 3 3.04
466151.51.5
22 22
S100-02443 3 4.54 6
66151.51.5
20 20
S100-02453 3 5.59 8 10 8
15 1.5 1.5
20 20
S100-02463 3 8.18 10 15 16
15 1.5 1.5
18 18
S100-03413 3 13.18 16 20 16
15
2.5
1.5
16 16
S100-03423 3 16 20 25 20 20
2.5 1.5
14 14
