Control Techniques UD53 User Manual

UD53 User Guide
Issue code: 53nu3
19
16.06 Simulated encoder output select
ô 0 ~ 1 ð 0 RW Bit
Note
This parameter is available only with the following:
UD53 version 2 onward
Drive software version V03.xx.07 onward
Set 16.06 as follows to select the required source for the simulated-
encoder outputs:
16.06 Source
0Resolver
1Encoder 1
The simulated-encoder outputs appear on the following terminals:
Terminal Function
Quadrature
AB
Frequency
and
direction
40 A F
41 A\ F\
43 B D
44 B\ D\
46 Z Z
47 Z\ Z\
16.07 Simulated-encoder output scaling
ô 0 ~ 15 ð 02
n
RW Uni
Enter the required value in 16.07 for scaling the simulated-encoder output.
The scaling factor is as follows:
1
2
16 07[.]
For example, for a division of
1
/
16
, set 16.07 at 4 (16 = 2
4
)
