16.08 Simulated-encoder F/D output enable
ô 0 ~ 1 ð 0 RW Bit
Use 16.08 to select the output mode of terminals 40, 41, 43, 44, as follows:
16.08 Output mode
0 AB quadrature signals
1 Frequency and direction signals
16.09 Resolver phase offset
ô 0 ~ 6143 ð 1/6143 rev. RW Uni S P
16.09 indicates the value of phase offset. See Phase offset in Chapter 5
Setting up the UD53 for ways in which the value is entered.
The value is saved at power-down and is changed only when one of the
procedures indicated in Phase offset is performed.
When the operating mode of the Drive is changed, 16.09 is reset to zero.
Restoring default values does not affect the value of 16.09.
16.10 Resolver turns ratio select
ô 0 ~ 1 ð 0 RW Uni
Note
This parameter is available only with the following:
UD53 version 2 onward
Drive software version V03.xx.07 onward
Set 16.10 as follows to select the required resolver turns ratio:
16.10 Turns ratio
03:1
12:1
