2-46
1010PVNFM-3A
Section 2
Max Flow
The [Max Flow] menu cell stores the maximum range for the flow rate output (Vfo). It can be
a positive or negative value. Enter the data using the flow rate units you selected. This entry
also spans the unsigned flow variable (Vfab).
To enter the Max. Flow Range Setting:
To activate numeric entry press
Use the numeric keys to type the maximum flow rate (100% of range).
To store the data press
Min Flow
The [Min Flow] menu cell stores the minimum range for the flow rate output (Vfo). It can be a
positive or negative value (to reflect bi-directional flow). However, the minimum span for the
unsigned flow (Vfab) is always zero. Enter the data using the flow rate units you selected.
To set the Min. Flow Range:
To activate numeric entry press
Use the numeric keys to type the minimum flow rate (0% of range).
To store data press
The following Span Data items are set in the same way as the two previously shown examples
by entering numeric values and storing the data.
Max LiquIdent
The [Max LiquIdent] menu cell stores the maximum range value for the LiquIdent function.
Min LiquIdent
The [Min Liquident] menu cell stores the minimum range value for the LiquIdent function.
Max Vs m/s
The [Max Vs m/s] menu cell stores the maximumrange value (in m/s) for the LiquIdent func-
tion.
Min Vs m/s
The [Min Vs m/s] menu cell stores the maximum range value (in m/s) for the LiquIdent func-
tion.
ENT
ENT
1010PVCDN (Expanded 1010N-7 I/O Module)
Installation Drawing 1010N-7-7 (Sheet 3 of 3)
(Ultra Performance Flowmeters)
PIN# SIGNAL FUNCTION NOTES
9 PG1 PRIMARY FREQUENCY OUTPUT / OPEN COLLECTOR Digitally Synthesized
10 PG2 PRIMARY FREQUENCY OUTPUT / TTL Pulse Waveform
11 PG3 QUADRATURE FREQUENCY OUTPUT / OPEN COLLECTOR
12 PG4 QUADRATURE FREQUENCY OUTPUT / TTL
TB2
To Next Page
