Controlotron 1010PVDN - Analog Output Setup; 1010 PVN Analog Outputs; Analog out Setup Data Categories

2-61
1010PVNFM-3A
Section 2
2.10.1 ANALOG OUTPUT SETUP
The 1010PVN provides current, voltage and pulse-rate analog outputs. Analog Output Setup
allows you to assign data functions for these signals. The flow computer’s terminal strip con-
tains the analog output terminals.
Io (Isolated current) 4 to 20 mA varies in proportion to an assigned data function.
Vo (DC voltage) 0 to 10 Vdc varies in proportion to an assigned data function.
Pgen (TTL logic) 0 to 5000 Hz varies in proportion to an assigned data function.
1010PVN Analog Outputs
THE I/O DATA CONTROL MENU STRUCTURE (continued)
I/O Data Control Analog Input Setup Iin1 Input Off
4 mA *numeric entry Aux
20 mA *numeric entry cS
PSIA
BARA
T1 Deg F
T1 Deg C
T2 Deg F
T2 Deg C
Iin2, Iin3, Iin4 See Iin1 above See Iin1 above
ô
ð
ô
ô
ô
ð ð
ð
NOTE 1: For Multi-Path flowmeters: “1” = Path 1, “2” = Path 2 and “S” represents the system or average path.
These characters appear to the left of the option list parameter.
*NOTE: 2: Signals lin3 and lin4 are for Multi-beam and Arithmetic operation modes only.
S Vfo System spanned volumetric flow (unsigned).
S Vfab System spanned and signed absolute flow.
S Vs System liquid sonic velocity.
S Valc System signal amplitude.
S Vaer System aeration number.
S LiquIdent m/s System sonic velocity compensated for temperature.
S Viscosity System liquid viscosity.
S T1 Current liquid temperature.
Iin1, Iin2, Iin3*, Iin4* Represents a re-transmit of the analog input signals (e.g.,
Pressure and Temp inputs can be transmitted on the 4/20 mA
output).
Analog Out Setup Data Categories
NOTE: For Expanded I/O modules, refer to drawing 1010N-7-7 and Addendum
1010FMA-14 for details.
Model Number and I/O Module Installation Drawing and Page Number*
1010PVN 1010N-2-7 (Sheet 2 of 2)
1010PVN with 1010N-7 Expanded I/O Module 1010N-7-7 (Sheet 2 of 3)
1010PVDN 1010N-2-7 (Sheet 2 of 2)
1010PVDN with 1010N-7 Expanded I/O Module 1010N-7-7 (Sheet 2 of 3)
Table To Determine Proper I/O Installation Drawings
*Note: For Ultra Precsion transducers see 1010N-7-7 (sheet 3 of 3).
