Section 2
THE I/O DATA CONTROL MENU STRUCTURE
(Note: For Multi-Path flowmeters: “1” = Path 1, “2” = Path 2 and “S” represents the
system or average channel. These characters appear to the left of the option list pa-
rameter.)
(continued)
I/O Data Control Analog Output Setup Io1 S Vfo
S Vfab
S Vs
S Valc
S Vaer
S LiquIdent m/s
S Viscosity
S T1
Iin1
Iin2
Iin3*
Iin4*
Io2 See Io1 option list
Vo1 See Io1 option list
Vo2 See Io1 option list
Pgen 1 See Io1 option list
Pgen 2 See Io1 option list
Relay Setup Relay 1 Off
Power On
S High Liquident
S Low Liquident
S High Viscosity (2-Path only)
S Low Viscosity (2-Path only)
S Hi Temperature
S Low Temperature
S High Flow
S Low Flow
S Flow Alarm
S Fault Alarm
S Spacing
S Empty
S Aeration
S Interface
S Reverse Flow
S BatchTot
S Pos Total
S Neg Total
S Fltwarn (2-Path only)
S Soft Fault
S Pig Detect
Relay 2 See Relay 1 list
Relay 3 See Relay 1 list
Relay 4 See Relay 1 list
ô
ô
ô
ð
ð
ð
ð
ð
ð
ð
ð
ð
ô
ð ð
ð
ô
ô
ô
ð
ð
ð
ð
ð
ð
ð
*For Multi-Beam and Arithmetic operating modes only.
