CONVAID USER’S GUIDE
9
Positioning Belts
Positioning Guide
The Cuddle Bug comes with either a two-point or a three-point positioning belt.
Both can be attached to the back of the seat (to achieve a 45 degree lap belt
angle) or to the sides of the seat pan (to achieve a 60 degree lap belt angle)
Fig. 19-20. To attach the belts to the chair, open the plastic clip located at the
ends of the positioning belts and thread it through the desired fabric loop, then
press clip together until it clicks shut. Fig. 20-22
Fig.19 Two-point positioning belt Fig.20 Three-point positioning belt
Fig.22 Seat BackFig.21 Seat Pan
