CONVAID USER’S GUIDE
15
Height Adjustable Armrest
Foot Positioner
To adjust height of armrests, loosen
the two round knobs and slide armrest
to desired position, re-tighten knobs.
Fig. 38
The foot positioner holds the foot securely in place. To attach, select desired
location on the footplate and press down to Velcro. Fig. 39a & 39b
Fig.38
Fig.39a
Fig.39b
