12
POSITIONING GUIDE
Lateral Thoracic Spports
Lateral thoracic supports are used to maintain midline positioning of the trunk.
To Open: Press latch located at top of thoracic support and pull outward until it
snaps into place. Fig. 30
Height Adjustment: Loosen two adjustable levers on the back of the chair by
rotating them counter clockwise. Slide thoracic support vertically to desired posi-
tion, and tighten levers. Fig. 31
Width Adjustment: Loosen two adjustable levers on the back of the chair, slide
thoracic support horizontally to desired position, and tighten levers. Fig. 32
To Fold: Press latch located at the top of the thoracic support and fold inward
Fig. 33.
Fig.30 Fig.31
Fig.32
Fig.33
