POSITIONING GUIDE
Height Adjustable Push Handle
Angle Adjustment:
Press and hold the grey detent button. Fig. 40 While holding the detent button,
adjust the handle to desired angle and release button. Fig. 41
Height Adjustment:
Pull the black knob located on the bottom of the push handle’s arms and
turn one quarter of the way. Fig. 42 Swing the push handle forward or backward
to desired height, and turn black knob back into original position. Fig. 43
Fig.40 Fig.41
Fig.42 Fig.43
