4
SETTING UP
Fig.10 Fig.11
Fig.12
Fig.13
6. Once the chair is in the Lo position, locate the red loop next to the Hi/Lo lever
and pull to the far left with an index finger. Fig. 10
7. While holding the red loop, squeeze the recline lever on the right side of the
chair's handle and recline the back all the way down. Fig. 11& 12
8. Push in grey detent buttons
on the handle, and rotate
handle back into chair.
9. Push in grey detent buttons
on the footplate, and rotate
footplate back under chair.
Fig. 13
10. With a straight back, bend
knees and lift chair.
