Convaid Rodeo - H-Harness with Padded Covers; Two-Piece Seat

8
Two-piece Seat
The lower seat panel has a
double Velcro® attachment
for adjusti ng the seat. To
adjust the tautness of the
seat, pull apart the double
Velcro flap at the rear under-
si de of the seat. Place the
Velcro i n the desi red posi -
ti on and reattach the double
flap. Fig. 28
Fig. 28
FITTING GUIDE
Fig. 26
Fig. 27
H-harness shoulder straps
help the user retain upright
trunk posi ti on. To adjust
the hei ght, i nsert the bolt at
the en d of the str a p thr ou gh
the gromm et hole i n the seat
back, and secure wi th the
threaded knob. Gromm et
choi ce should be level wi th
or hi gher than the top of the
shoulders - this wi ll keep
the user secure, wi thout the
strap rubbing against the
fa ce or neck. Fig. 26 & 27
H-Harness with Padded Covers
