Fig. 83
Fig. 84
26
WHEELS
Fig. 82 Unlocked
To unlock, push up on Red
Brake Lever until you hear a
“CLICK.”Fig. 82
Rear Tire Removal
To remove, press down and
hold the Rea r Wheel Locki n g
Pi n. Grasp wheel and pull.
Note: No tools a r e requ i r ed
to remove ti re.
Rear Wheel Locking Pin
