FITTING GUIDE
Seat Depth
Seat Depth Adjustment:
1. Remove bolts located on the front of
seat frame. Fig. 23
2. Adjust seat to desi red positi on and
reinsert bolts.
Mea sure from the most posteri or porti on of the buttocks
to the ba ck of the knee. Su btr a ct fr om tha t m ea su r em en t
1-2” to allow adequate clearance between the seat and
the ba ck of the knee. Fig. 22
Seat depth
Fig. 22
Fig.23
Fig. 21
Seat wi dth i s
measured from
the outsi de edge of
the seat frame.
Fig. 21
Note: Adjust one si de of the seat at
a time.
