Fig. 67 Fig. 68 Fig. 69
21
CONVAID USER’S GUIDE
Attendant Hand Brake
Fig. 66
Hand brakes help to maintain control of the
chair when going down an incline. A moderate
squeeze to the lever wi ll slow the chai r; a fi rm
squ eez e w i ll stop the cha i r. Fig. 66
Recline
Brake
Caution:
Always make sure the wheels are installed
properly. You will hear a “click”when the
wheel locks into place.
!
Attendant Hand Brake - Tire Installation:
Slide wheel onto rear axle, and push on wheel until it clicks into place. Fig. 67 - 69
Important: Before pushing on wheel, make sure the brake band is flush with the
i nsi de of the brake housi ng.
Attendant Hand Brake - Tire Removal: See Page 26
