5. All floor ti e-down straps must be drawn ti ght i n the front and the back to
eliminate any forward/aft movement of the chair.
6. Restraint manufacturers’ instructions must be followed precisely.
Note: Tray, storage basket, canopy and oxygen tank bag must be removed during
transport i n bus or van, except when medically neccessary.
Q’ Straint America Sure-Lok Ortho Safe Systems, Inc.
Tel: 1-800-987-9987 Tel: 1-866-787-3565 Tel: 1-609-587-9444
Fax: 1-954-986-9987 Fax: 1-610-814-0644 Fax: 1-609-587-6780
5553 Ravenswood Road #110 2501 Baglyos Circle PO Box 8865
Ft. Lauderdale, FL 33312 Bethlehem, NJ 18020 Trenton, NJ 08650
USA USA USA
CONVAID USER’S GUIDE
23
Transit Models
All bus transport models have been crash-tested and
performed sati sfactori ly at 30 mph / 20 g decelerati on.
Dummy wei ghts as tested:
Rodeo
Model RD10T 66 lbs / 30 kg
Model RD12T 66 lbs / 30 kg
Model RD14T 100 lbs / 45.5 kg
Model RD16T 140 lbs / 63.5 kg
To reduce possi bi li ty of i njury, the headrest
extension must always be used with the chair.
The followi ng instructi ons should be followed to
dupli cate test results:
1. Chai r must be forward faci ng wi th
tray and storage basket removed.
2. Use only a tested, proven and compatible
4-poi nt wheelchai r ti e-down system, and a
3-point occupant restrai nt system i n
accordance with SAE J2249.
3. The wheelchai r ti e-downs m ust be securely
atta ched to the four red a nchor poi nts on
the chair. See arrows in above photo for
anchor points.
4. The occupant restraints must include a lap
and shoulder belt, secured directly to the
floor and si de or roof of the vehi cle.
Caution:
Convaid belts and
shoulder straps are
for positioning only
and are not to be used
as a vehicular restraint.
!
