CONVAID USER’S GUIDE
11
Folding Lateral Supports:
The la teral supports help mai ntai n m i dli ne posi ti oni ng of the trunk.
To adjust the lateral supports:
1. Release the velcro upholstery straps on the back si de of the chai r.
2. Loosen the knobs on the latera l mounti ng bracket.
3. Reposi ti on laterals to the desi red locati on.
4. Ti ghten the knobs and replace the upholstery. Fig. 36
Lateral Supports
Fig.36
Fig.37
Convai d offers a wi de vari ety of supports to help properly posi ti on the user.
Note: Convaid’s chairs provide a semi-contour fit around the body. The user must
be fitted correctly into the chair to achieve optimal posture and comfort.
Additional Supports
Lateral Supports
To fold laterals, squeeze the latch located at
the bottom of Lateral Support Bar, a nd fold
inwards. Fig. 37 & 38
