Connecting up the combi steamer
Installation manual 49
Connection and installation diagram for the appliance
The following diagram shows the connection diagram for water installations without water treatment:
Z
DCV
Y
WX
200-600 kPa
5011002
4-20°dH
7-27°TH
5-19°e
70 - 270 ppm
0,7 - 2, 7 mmol/l
p 2 - 6 bar
Tmax.40°C
min. 20 µS/cm
pH 6,5 - 8,5
Cl
-
max. 100 mg/l
SO
4
max. 150 mg/l
Fe max. 0, 1 mg/ l
6019164
2-
4-7°dH
7-13°TH
5-9°e
70 - 125 ppm
0,7-1,3mmol/l
p 2 - 6 bar
Tmax.40°C
min. 20 µS/cm
pH 6,5 - 8,5
Cl
-
max. 100 mg/l
SO
4
max. 150 mg/l
Fe max. 0,1 mg/ l
6019165
2-
The following diagram shows the connection diagram for water installations with water treatment:
Y
Y
X
200-600 kPa
200-600 kPa
Z
DCV
4-20°dH
7-27°TH
5-19°e
70 - 270 pp m
0,7 - 2,7 mm ol/ l
p2-6bar
Tmax.40°C
min. 20 µS/cm
pH 6,5 - 8,5
Cl
-
max. 100 mg/l
SO
4
max. 150 mg/l
Fe max. 0,1 mg/l
6019164
2-
4-7°dH
7-13°TH
5-9°e
70 - 125 ppm
0,7 - 1,3 mmol/l
p 2 - 6 bar
Tmax.40°C
min. 20 µS /cm
pH 6,5 - 8,5
Cl
-
max. 100 mg/l
SO
4
max. 150 mg/l
Fe max. 0,1 mg/l
6019165
2-
A
B
WV
Item Name Explanation
A
Soft water connection
S
Cold water connection
Z
Water supply line
X
Sediment filter 0.08 mm
A 0.08 mm sediment filter must be installed if the water has a high
level of impurity.
W
Activated carbon filter
If the redox potential of the water exceeds 300 mV and if the
chlorine concentration (Cl
2
) > 0.1 mg/l then an activated carbon
filter must be installed.
V
Partial deionizer
If the water hardness exceeds the permitted level, a partial deion-
izer must be installed. The partial deionizer only needs enough
capacity to treat the water for demoisturization (Crisp&Tasty) and
steam generation.
Y
Shut-off device with dirt filter
