DESCRIPTION
Query or change HVAC Line(s) status and configuration. In format without parameters line command will
provide information about current Line statuses. Second format is used to change write enabled properties.
<PROPERTY>
Mode
Value
Description
Notes
master
R/W
0 or 1
CoolMasterNet acts as a Master device
DK, LG, SA, TO,
PN
only
simul
R/W
integer
Simulate given number of Indoor Units. To disable simulation use
"0". Simulation is persistent (not disabled after power reset)
By default the simulation model is: with failures, no ventilation
units, no input/output units. To enable/disable special conditions
use the following flags:
+/-flr, +/-vam, +/-io (see example)
Input/Output units
for ME only
Ventilation units
for DK, ME, LG
only
myid
R/W
string
CoolMasterNet Own address on given HVAC Line.
For ModBus RTU Line myID is a "Slave Device Address"
baud
R/W
Configure UART parameters for given Line. Value format is:
<BAUD> <8|9><N|E|O><1|2>
For example: 9600 8N1
Where applicable
Tx
RO
integer
counter
Transmitted messages
Printed as
Last/Total
Last means since
previous print
Rx
RO
Received messages
TO
RO
Timeout errors
CS
RO
Checksum errors
Col
RO
Collision errors
NAK
RO
NAK errors
haux
R/W
heat or
haux
Heat mode treated as Haux mode. This is only for situation when
HomeAutomation controller doesn't have Haux support, but need
to set Haux mode on ThermoPad(s)
connected to CH line.
For CoolHub
(CH) line only
type
R/W
string
Define line type by acronym. Number of HVAC lines cannot
exceed the value of HVAC lines in set command.
HomeAutomation/BMS lines don't count as HVAC Lines.
To free a line use Unused instead of acronym.
See the full list
of HVAC and
HomeAutomatio
n/BMS lines
supported
scan
R/W
0 or 1
Implicitly detect Indoor Units
ME, HT, SA, TO,
PN only
DCOUT
R/W
- or +
Control DC output on L1,L2
DK,ME only
slink
R/W
O/o or
N/n
Configure Mitsubishi Heavy SuperLink mode: O - old, N -
new
MH only
Configure Samsung model type: O - DVM, N - DVM-S
SM only
[A|B] or [B|A]
RO
Current polarity
Line L7 only
EXAMPLE
>line
L1: SA U00/G02 myID:E5
Tx:732/732 Rx:47227/47227 TO:0/0 CS:0/0 Col:0/0 NAK:0/0
L2: DK Master U00/G07 myID:0B
Tx:4579/4579 Rx:50633/50633 TO:3/3 CS:0/0 Col:10/10 NAK:0/0
L3: Unused
