Notes:
Subnet ID and Device ID of HDL RS485 line can be changed with line myid command.
EXAMPLE
List existing AC configurations
>hdl
Ch | AC | En | Remark | CA | CHFAD | AHML |
--- ---- ---- ---------------- -------- ------- ------
1 | 1 | 1 | L1.100 | L1.100 | ++--- | -+-+ |
2 | 2 | 1 | L1.101 | L1.101 | ++++- | ++++ |
OK
Delete AC configuration for Indoor Unit L1.101
>hdl - L1.101
OK
Create AC configuration for Indoor Unit L2.301: channel=2, AC number=2, valid, modes=cool heat, fan
speeds=high medium
>hdl + L2.301 2 2 1 ++----+-+
OK
HDL ethernet status
>hdl eth
status : enabled
ID : 0x01 0x63
send cntr : 0
recv cntr : 0
crc cntr : 0
OK
Enable HDL over ethernet
>hdl eth enable
OK, Boot Required!
Change HDL ID of CoolMasterNet: Subnet ID=0x01=1, Device ID=0x63=99
>hdl eth myid 0163
OK, Boot Required!
simul
SYNOPSIS
simul [Ln] <CNT>
DESCRIPTION
Simulate <CNT> Indoor Units on HVAC Line <Ln>. If <Ln> is omitted the first not "Unused" HVAC Line will be
taken. Simulation is not persistent and CoolMasterNet reset will terminate it.
EXAMPLE
Simulate 5 Indoor Units on HVAC Line L2
>simul L2 5
OK
gpio
SYNOPSIS
gpio
gpio func <A|B|C|D> <GPIO_FUNCTION>
