Layout
1.
USB Host, HVAC Line L8
2.
Power
3.
Power Plug
4.
RS232 Port
5.
HVAC Line L1
6.
HVAC Line L2
7.
HVAC Line L3 or RS485 Port
8.
Ethernet Port
9.
GPIO
10.
HVAC Line L7
11.
HVAC Line L6
12.
HVAC Line L5
13.
HVAC Line L4
14.
USB Device Port
15.
DIP Switches P,Q, R,S
16.
LCD with Touch Screen
