COOLIUS A10 / Y10
6.2 Output test
It is possible to activate the devices connected to the mainboard “A” (PWR).
NOTE: Both quick couplers must be installed!
Turn COOLIUS SELECT to select the output to be activated.
Press ENTER to activate the selected OUTPUT.
NOTE: In order to avoid the exit of refrigerant from the vacuum pump outlet or from the Oil/UV bottles, the
activation of VP, UV, NO and of all the combinations containing at least one of them, are possible only when
the pressure is lower than 1100 mb.
• CP Compressor and Compressor fan
• VP Vacuum pump
The HP and LP gauges must show 0 (Zero) bar!
• EO Used oil drain valve
• UV Dye tracer valve
The HP and LP gauges must show 0 (Zero) bar!
• NO New oil valve
The HP and LP gauges must show 0 (Zero) bar!
• RF Refrigerant valve
• XP Recovery valve
• LP Separation valve
• A1 Aggregate valve
• A2 Aggregate valve 2
• CP+XP
• VP+LP
The HP and LP gauges must show 0 (Zero) bar!
• CP+XP+LP
