6
COOLIUS A10 / Y10
1.1 Flow diagram - SPARE PARTS LIST
N° DESCRIPTION CODE
01 SERVICE COUPLING HP (A10) 0605115006
SERVICE COUPLING HP (Y10) 0605512006
02 SERVICE COUPLING LP (A10) 0605115001
SERVICE COUPLING LP (Y10) 0605512001
03 HP GAUGE (A10 / Y10) 0710175085
04 LP GAUGE (A10 / Y10) 0710145085
05 3 m SERVICE HOSE HP (A10) 0603015030
3 m SERVICE HOSE HP (Y10) 0603019030
06 3 m SERVICE HOSE LP (A10) 0603010030
3 m SERVICE HOSE LP (Y10) 0603013030
07 COMPLETE MANIFOLD (A10) 0510003011
COMPLETE MANIFOLD (Y10) 0510005005
7a
ELECTRIC VALVE GROUP “1A”
(LP / XP / RF / A1* / EO)
0500142050
7b
ELECTRIC VALVE GROUP “1B”
(NO / UV / VP)
0500142075
08 ELECTRONIC PRESSURE TRANSDUCER 0712350007
09 CHECK VALVE - RECOVERY (G1/8 FF) 0501086062
10 VACUUM PUMP 100L 0417023122
12 CHARGE HOSE (A10) 0603055361
CHARGE HOSE 7/16 UNF(O-RING) (Y10) 0603400217
13 RECOVERY HOSE W/VALVE + ADD.CHECK VALVE (A10) 0613010401
RECOVERY HOSE 7/16 UNF(O-RING) (Y10) 0603400235
15 BY-PASS KIT (A10) 0612400070
BY-PASS KIT (Y10) 0612401055
20 COMPRESSOR 1/3 HP 0420190022
21 CAPILLARY 0602099575
23 OIL DISTILLER GROUP (A10) 0611013002
OIL DISTILLER GROUP (Y10) 0611013005
24 MAIN FILTER 0607350344
25 HIGH PRESSURE SWITCH 0703014019
26 COMPRESSOR FAN (D172 230V - LONG CABLE FAN) 0408172053
27
ELECTRIC VALVE GROUP “1A”
(LP / XP / RF / A1* / EO)
0500142050
28 COMPRESSOR COPPER PIPE 0602004101
29 CHECK VALVE - OIL DISTILLER (7/16UNF O-Ring M - G1/4 F) 0501071614
30 LIQUID RECEIVER 11L GROUP (A10) 0612010012
LIQUID RECEIVER 11L GROUP (Y10) 0612011005
31 HEAT BELT 0404550058
32 OVERPRESSURE VALVE 0503016045
33 SAFETY VALVE D7 0503144020
34 INTERNAL VESSEL ADAPTER GROUP (A10) 0612510009
INTERNAL VESSEL ADAPTER GROUP (Y10) 0612511003
