2. Specifications
2.1 Unit Specifications
Parameter Unit Value Value
Model --
CH-S09FTXN-E2wf
Product Code -- SCB001N0011 SCB001N0021
Power Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases -- 1 1
Power Supply Mode -- outdoor outdoor
Cross-sectional Area of Power Cable Conductor mm2 1.0 1.0
Recommended Power Cable(Core) N 3 3
Min/Max. Voltage V 198/264 198/264
Cooling Capacity Btu/h 8530 11600
Min. Cooling Capacity Btu/h 2660 4436
Max. Cooling Capacity Btu/h 9895 13306
Heating Capacity Btu/h 9554 12283
Min. Heating Capacity Btu/h 2491 2730
Max. Heating Capacity Btu/h 11260 14330
Cooling Power Input W 580 790
Min. Cooling Power Input W 75 90
Max. Cooling Power Input W 1430 1560
Heating Power Input W 650 800
Min. Heating Power Input W 135 140
Max. Heating Power Input W 1550 1650
Cooling Current A 3.4
4.7
Heating Current A 3.4 4.4
Rated Input W 1550 1650
Rated Current A 6.9 7.3
EER W/W 4.32 4.32
COP W/W 4.51 4.51
Air Flow Volume m3/h 520/440/230/150 550/470/250/180
Dehumidifying Volume L/h 0.80 1.40
Dehumidifying Volume PINT/D 1.69 2.96
Application Area m2 12-18 16-24
Indoor Unit
Indoor Unit Model --
Fan Type -- Cross-flo Cross-flo
Fan Diameter Length(D×L) mm Ф97.5×579 Ф97.5×579
Cooling Speed r/min 1300/1150/750/600 1350/1200/800/650
Heating Speed r/min 1300/1150/850/800 1350/1200/900/850
Fan Motor Power Output W 18 18
Fan Motor RLA A 0.2 0.2
Fan Motor Capacitor μF 1 1
Evaporator Form -- Alumium Tube Alumium Tube
Evaporator Pipe Diameter mm φ5 φ5
Evaporator Row-fin Ga mm 2-1.4 2-1.4
Evaporator Coil Length (L×D×W) mm 584.4×22.8×266.7 584.4×22.8×266.7
Swing Motor Model -- 24BJ-A1 24BJ-A1
Swing Motor Power Output W 1.5 1.5
Fuse Current A 3.15 3.15
Set Temperature Range
℃
16~31 16~31
Set Temperature Range
℉
61~88 61~88
Sound Pressure Level dB (A) 40/36/24/19 41/37/25/20
Sound Power Level dB (A) 54/39/36/30 55/40/37/31
Dimension (W×H×D) mm 792x279x195 792x279x195
Dimension of Carton Box (W×H×D) mm 868x280x349 868x280x349
Dimension of Package (W×H×D) mm 871x290x352 871x290x352
Stacked Layers - 7 7
Net Weight kg 9 9
Gross Weight kg 11.5 11.5
Parameter Unit Value Value
Outdoor Unit
Outdoor Unit Model --
Compressor Trademark panasonic SANYO
Compressor Model -- 5SS072ZJA21 C-1RZ110H1AE
Compressor Oil -- FV50S or equivalent
FV50BX
Compressor Type -- Rotary Rotary
Compressor LRA. A 21 25
Compressor RLA A 3.1 3.5
Compressor Power Input W 680 780
Fan Type -- Axial-flo Axial-flo
Fan Diameter mm 405 405
Fan Diameter inch 15.9 15.9
Fan Motor Speed rpm 880 880
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Outdoor Unit Air Flow Volume m3/h 1800 1800
Condenser Form -- Alumium Tube Alumium Tube
Condenser Pipe Diameter mm φ7.94 φ7
Condenser Rows-fin Ga mm 1-1.4 2-1.4
Condenser Coil Length (L×D×W) mm 742×19.05×506 719×38.1×506
Permissible Excessive Operating Pressure for the
Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for the
Suction Side
MPa 2.5 2.5
Maximum Allowable Pressure MPa 4.3 4.3
Cooling Operation Ambient Temperature Range
℃
18~48 18~48
Cooling Operation Ambient Temperature Range
℉
64~118 64~118
Heating Operation Ambient Temperature Range
℃
-23~24 -23~24
Heating Operation Ambient Temperature Range
℉
5~75 5~75
Throttling Method -- Electron expansion valve
Electron expansion
valve
Defrosting Method -- Automatic Defrosting Automatic Defrosting
Climate Type -- T1 T1
Climate Zone -- Temperate Zone Temperate Zone
Isolation -- I I
Moisture Protection -- IP24 IP24
Sound Pressure Level dB (A) 52 53
Sound Power Level dB (A) 61 62
Dimension (W×H×D) mm 830X540X325 830X540X325
Dimension of Carton Box (W×H×D) mm 876x585x363 876x585x363
Dimension of Package (W×H×D) mm 879x605x366 879x605x366
Stacked Layers -- 5 5
Net Weight kg 29 30.5
Gross Weight kg 32 33.5
Refrigerant -- R410A R410A
Refrigerant Charge kg 0.7 0.90
Connection Pipe
Length m 5 5
Length ft 16.4 16.4
Gas Additional Charge g/m 20 20
Gas Additional Charge oz/ft. 0.2 0.2
Outer Diameter of Liquid Pipe(GREE Allocation)
(Metric)
mm φ6 φ6
Outer Diameter of Liquid Pipe(British System
Allocation)
inch 1/4" 1/4"
Outer Diameter of Gas Pipe(GREE Allocation)
(Metric)
mm φ9.52 φ9.52
Outer Diameter of Gas Pipe(British System
Allocation)
inch 3/8" 3/8"
Max Distance Height m 10 10
Max Distance Height ft 32.8 32.8
Max Distance Length m 20 20
Max Distance Length ft 65.6 65.6
CH-S12FTXN-E2wf
CH-S09FTXN-E2wf
CH-S12FTXN-E2wf
CH-S09FTXN-E2wf
CH-S12FTXN-E2wf
