Construction ViewsConstruction Views
3. Construction Views
3.1 Indoor Unit
Unit:mm
Model W(mm) H(mm) D(mm)
CH-S09FTXN-E2wf
792 279 195
CH-S12FTXN-E2wf
792 279 195
CH-S18FTXN-E2wf
972 302 224
CH-S24FTXN-E2wf
1081 327 248
CH-S09FTXN-E2wf
CH-S12FTXN-E2wf
CH-S18FTXN-E2wf
3.2 Outdoor Unit
Unit:mm
Model:
CH-S09FTXN-E2wf
CH-S12FTXN-E2wf
960
340
700
368
560
396
Model: CH-S18FTXN-E2wf
CH-S24FTXN-E2wf
W
H
D
CH-S24FTXN-E2wf
540
290
830
762
540
257
325
