Cooper Power Systems NOVA 15 - Ratings and Specifications; Check Recloser Ratings Prior to Installation

Check Recloser Ratings Prior To
Installation
The recloser must be applied within its specified ratings.
Check data plate ratings and compare with the system
characteristics at the point of application prior to installa-
tion. Tables 1, 2, 3, and 4 list the ratings and specifications
for the Type NOVA recloser. Table 5 lists the auxiliary-
powered interface power requirements.
Type NOVA Three-Phase, Microprocessor-Controlled Recloser Installation and Operation Instructions
4
RATINGS AND SPECIFICATIONS
TABLE 5
Auxiliary-Powered Interface Power Requirements
Voltage Normal Current Operating Current Duration Recommended Power
120 VAC 0.2 A 1.0 A 3 sec 150 VA
240 VAC 0.1 A .5 A 3 sec 150 VA
125 VAC 0.2 A 1.0 A 3 sec 150 VA
250 VAC 0.1 A .5 A 3 sec 150 VA
TABLE 4
Duty Cycle
Percentage of Number of Minimum
Type Interrupting Rating Unit Operations Circuit X/R Value
NOVA 15-20 88 4
45-55 112 8
100 32 17
*
Total 232
*Value shown for 60 Hz.
Description 15 kV 15 kV 27 kV 27 kV 38 kV
Min. Mechanical/Electrical Operations
Without Maintenance (C-O) 10,000 10,000 10,000 10,000 10,000
Mass (Weight) - kg (lbs) 86 (190) 91 (200) 91 (200) 101 (223) 101 (223)
TABLE 3
Mechanical Ratings
Description 15 kV 15 kV 27 kV 27 kV 38 kV
Maximum Voltage 15.5 kV 15.5 kV 29.2 kV 29.2 kV 38.0 kV
Rated Basic Impulse Level 110.0 kV 125.0 kV 125.0 kV 150.0 kV 170.0 kV*
Radio Noise Limit (µv) 100 @ 9.4 kV 100 @ 9.4 kV 100 @ 16.4 kV 100 @ 16.4 kV 100 @ 23.0 kV
Power Frequency Withstand, Dry 50 kV 50 kV 60 kV 60 kV 70 kV
Power Frequency Withstand, Wet 45 kV 45 kV 50 kV 50 kV 60 kV
TABLE 1
Voltage Ratings
*170 kV beginning with S/N CP571192790; S/N 1000 through S/N CP571192789 are rated 150 kV BIL or less — as indicated on the nameplate.
*800 amp accessory is also available.
**16.0 kA option is also available. (Making Current is 41.0 kA Asymmetrical Peak.)
Description 15 kV 15 kV 27 kV 27 kV 38 kV
Rated Continuous Current 630 A* 630 A* 630 A* 630 A* 630 A*
Short Circuit Current, Symmetrical 12.5 kA** 12.5 kA** 12.5 kA** 12.5 kA** 12.5 kA
Making Current, Asymmetrical Peak 32.0 kA 32.0 kA 32.0 kA 32.0 kA 32.0 kA
Cable Charging Current 10 A 10 A 25 A 25 A 40A
TABLE 2
Current Ratings (Amperes)
