Form 5/Triple-Single and Form 5/Triple-Single UDP Control DIF Module 1
Outputs
The 12 outputs of the DIF Module are Form C relay contacts. Six of the outputs are latching and six are non-latching.
Note: Contacts shown in inactive mode.
Output Connector Function Type Description
1 P3-1 (NC) Ground Trip Blocked unlatched
P3-2 (NO)
2 P3-3 (NC) Non-Reclosing unlatched
P3-4 (NO)
3 P3-5 (NC) Battery Test unlatched
P3-6 (NO)
4 P3-7 (NC) Hot Line Tag unlatched
P3-8 (NO)
5 P3-9 (NC) Normal Profile unlatched
P3-10 (NO)
6 P3-11 (NC) Supervisory Blocked unlatched
P3-12 (NO)
7 P2-1 (NO) Phase A Lockout Latched
P2-2 (NC)
8 P2-3 (NO) Phase B Lockout Latched
P2-4 (NC)
9 P2-5 (NO) Phase C Lockout Latched
P2-6 (NC)
10 P2-7 (NO) Phase A Closed Latched
P2-8 (NC)
11 P2-9 (NO) Phase B Closed Latched
P2-10 (NC)
12 P2-11 (NO) Phase C Closed Latched
P2-12 (NC)
Normal Profile is active only when Alternate Profiles are
inactive. Normal reclosing operations will follow.
This output is active when the NON-RECLOSING indicator
in the operator panel is illuminated.
Supervisory Blocked prevents operation from supervisory
control. Programming is accessible from the operator panel.
This output is active when the SUPERVISORY BLOCKED
indicator on the operator panel is illuminated.
With Hot Line Tag active, close circuit is disabled and the
HOT LINE TAG indicator is illuminated. With Hot Line Tag
inactive, the control switched back to the previous time cur-
rent curve for the active profile, close circuit is enabled and
the HOT LINE TAG indicator is off. This output is active
when the operator panel indicator is illuminated.
Ground Trip Blocked causes the control to block ground trip-
ping operations. This output is active when the GND TRIP
BLOCKED INDICATOR on the operator panel is illuminated.
This output is active when the BATTERY TEST indicator on
the operator panel is illuminated. This is a momentary
function.
These outputs are active when the respective phase has
locked out.
These outputs are active when the respective phase has
closed.
