Return the Control to Service
Follow this procedure to return the control to service:
1. Connect cable to de-energized control and recloser.
2. Plug in the control battery.
3. Apply ac power to the control.
4. Verify that all control settings are correct.
5. Disable GND TRIP BLOCKED.
A. Press the CHANGE/LAMP TEST key on the Oper-
ator Panel to enter the CHANGE mode.
Note: The LCD Display Screen will indicate the amount
of time available in CHANGE mode to make a
change.
B. Depress the GND TRIP BLOCKED key.
Note: After the GND TRIP BLOCKED key is
depressed, the red LED indicator will not be illu-
minated indicating GROUND TRIP BLOCKED is
not active.
6. Reset the control clock after AC power has been re-
applied. (Refer Setting The Control Clock in Service
Information S280-79-2, Form 5 Microprocessor-
Based Recloser Control Programming Guide.)
Replacement Kits
Replacement kits for the Kyle
®
Form 5/Triple-Single Con-
trol are available through the factory Service Department.
To order these kits, refer to the Replacement Parts price
list for catalog numbers and pricing. Contact your Cooper
Power Systems representative for additional information
and ordering procedures.
Factory-Authorized Service
Centers
Factory-authorized service centers are located through-
out the continental United States to provide maintenance,
repair and testing services for Kyle controls and reclosers.
For further information, contact your Cooper Power Sys-
tems representative.
Factory Maintenance Classes
The factory service department offers a basic testing and
troubleshooting course for the Form 5/Triple-Single Micro-
processor-Based Electronic Recloser Control and NOVA-
TS Recloser. This course, taught by experienced service
technicians, is held at the factory’s in-house training facil-
ity. For additional information, contact your Cooper Power
Systems representative.
