Cooper VW - Bushing Parts List

S280-30-7
17
Item Catalog Quan.
No. Description Number Req’d.
12 Bushing ceramic—Type VW
Standard creepage KP1110R 1
Standard creepage with BCT
accy. KP171 W 1
17” extra creepage KP1578R 1
17” extra creepage with BCT
accy. KP186W 1
13 Bushing rod assembly—
Type VW
Standard and 17” creepage KA716R20 1
Standard and 17” creepage
with BCT accy. KA716R21 1
The following parts are applicable to the bushing current transformer
accessory.
14 Capscrew, hex hd,3/8-16 x 1-7/8,
stl K730101157187Q 3
15 Transformer clamping flange KP170W1 1
16 Flange gasket KP2090A73 2
17 Replacement current transformer
600:5 multi-ratio KA159W1S 1
1200:5 multi-ratio KA132W 1
18 CT washer KP312W 1
19 Capscrew, hex hd,3/8-16 x 1, stl K730101137100Q 3
20 Transformer clamping sleeve KP169W1 1
21 O-ring gasket, used with trans
former clamping sleeve that has
machined groove. Old style
clamping sleeve without
groove, use KP2090A66. KP2000A64 1
22 Hex nut, 3/8-16, stl K880201116037Q 3
23 Stud KP3149A40 1
24 Bushing spacer KP275W1 1
Item Catalog Ouan.
No. Description Number Req’d.
1 Bushing assembly—Type VW
consists of items 10 thru 13)
13” standard creepage KA717R25 6
13” standard creepage with
BCT accy. KA717R26 6
17” extra creepage KA717R27 6
17” extra creepage with BCT
accy. KA717R28 6
2 Bushing assembly—Type
VWV27 (Above S/N 974) and
Type VWV38
26-1/2” creepage KA56RV3 6
26-1/2” creepage with BCT accy. KA56RV4 6
Bushing assy. replacement kit—
Type VWV (below S/N 975)
includes bushing and
conductive gasket (9)
26-1/2” creepage KA842W1 6
26-1/2” creepage with BCT accy. KA842W2 6
3 Hex jam nut, 1/2-20, brass K880725320050H 12
4 Flat washer KP2028A903 12
5 Split lockwasher. med. 1/2.
bronze K900830050000A 6
6 Capscrew, hex hd, 3/8-16 x
2-1/4, stl K730101127225Q 18
7 Bushing clamp KP1109R 18
8 Clamping ring KP1111 R 6
9 Lower bushing gasket
Type VW KP2090A66 6
Type VWV27 and VWV38 KA1193R 6
10 Terminal assembly KA17W901 1
11 Upper bushing gasket KP2090A57 1
Bushing Parts (Figure 25)
