Cooper VW - Page 19

S280-30-7
19
Item Catalog Quan.
No. Description Number Req’d.
33 Lever and split shaft assembly KA312R 1
34 Retaining ring. Type C, 5/16,
stl, WA516 K970901312000M 1
35 Roil pin,1/8 x 3/4 K970801125075C 1
36 Retaining ring, Type C, 1/4,
stl, WA514 K970801250000M 2
37 One shot link and pin
assembly KA505R 1
38 Retaining ring, Type C,3/8.
stl, WA518 K970801375000M 2
39 Spacer KP3013A91 1
40 Groove pin KP3126A4 1
41 One shot handle assembly KA504R 1
42 Spacer KP301 OA5 1
43 Spacer KP3013A38 2
44 Indicator and support
assembly KA317R 1
45 Retaining ring, Type C,3/16
stl, WA510 K970915188000A 3
46 Groove Pin KP3123A12 1
47 Spacer K3006A9 1
48 Link KP1059R 1
49 Shaft and lever assembly KA319R 1
50 Pin KP3190A11 1
51 Spacer KP3007A8 1
52 Flatwasher, #14S brass K900525026056A 1
53 Cotter pin,3/32 x 1/2, stl K970801093050A 1
54 Roll pin,3/32 x 1/2, stl K970801093050C 1
55 Counter KA28COA2 1
56 Self-tapping screw, Type F.
6-32 x 3/8, sst K751515106037A 2
57 Bracket KP1598R 1
58 Self-tapping screw, Type Z.
#10 x 3/8, sst K801515010037A 2
59 Capscrew, hex hd,
1/2-13 x 3/4stl K730101150325Q 10
60 Flatwasher KP2028A23 10
61 Pipe plug, 1”, sq hd KP2007A4 1
62 Tank
29-1/2” high KRW116FA 1
25-1/2” high KRW116FC 1
63 Pipe plug, 1/2”, sq hd KP2007A3 1
64 Oil sampling and drain valve
assy. KA809R 1
65 Vacuum label KP1041V4H 1
Head and Tank Assemblies (Figure 26)
Item Catalog Quan.
No. Description Number Req’d.
1 Cover plate KP609R 2
2 Gasket KP611 R 2
3 Capscrew hex hd,
1/4-20 x 3/4 stl K730101125075Q 8
4 Split lockwasher, med,
1/4, sti K900801025000Z 8
5 Dipstick KA363R 1
6 O-ring gasket KP2000A9 1
7 Closing coil instruction plate KP2312R 1
8 Self-tapping screw, Type F.
#2 x 3/16, sst K751515102018A 2
9 Capscrew, hex hd,
1/4-20 x spa, stl K730101125062Q 2
10 Manual closing tool access
cover plate KP246R1 1
11 Cover plate gasket KP2000A12 1
12 Capscrew, hex hd,
5/8-11 x 1-1/2.stl K730101162150Q 2
13 Split lockwasher, med,
5/8, stl K900801062000Z 2
14 Lifting lug KP456H2 2
15 Ground connector KA392R 1
16 Head casting, includes control
shaft bushings KA840R 1
17 Head gasket KP2103A8 1
18 Nameplate
Type VW KRW107F1 1
Type VWV27 KRW127F1 1
Type VWV38 KRW173F 1
19 Voltage data plate KP567R 1
20 Coil data plate KP2119A9 1
21 Operating data plate KP1371R 1
22 Self-tapping screw, Type Z.
#4 x 3/16, sst K801515004018A 8
23 Sleet hood cover plate K283R 1
24 Thread cutting screw, Type T.
#12 x 1/2. sst K781515112050A 5
25 Contact indicator plate KP1067R 1
26 Handle designation plate KP390R 1
27 Self-tapping screw, Type F.
2-56 x 3/16, sst K751515102018A 4
28 Manual operating handle
assembly KA477R 1
29 Spacer KP3009A39 1
30 Lever and split shaft assembly KA313R 1
31 Spacer KP3011A5 1
32 Spacer KP3011A7 1
